Rear-leaf-spring-for-Ford-Transit-TT9-280-1-leaf
FORD
- model: +86-15689053701
| Specifications | |
|---|---|
| OEM | 1721779 |
| Top-3 models | Transit TT9 280 |
| Number of leaves | 1 |
| Maximum load, Pk, tons | 0,719 |
| Total weight, kilos | 13,1 |
| Working length of the leaf spring, L, mm | 1368 |
| L1, mm | 694 |
| L2, mm | 674 |
| Total thickness, H, mm | 24 |
| Free camber, Ho, mm | 87 |
| D1, mm | 58 |
| d1 bushing inner diameter, mm | 16 |
| D2, mm | 49 |
| d2 bushing inner diameter, mm | 14 |
| Schomaecker | 50611000 |
