Rear-leaf-spring-for-Ford-Transit-1-leaf
FORD
- model: +86-15689053701
| Specifications | |
|---|---|
| OEM | HK315560EE |
| Top-3 models | Transit |
| Number of leaves | 1 |
| Maximum load, Pk, tons | 0,719 |
| Total weight, kilos | 13,5 |
| Working length of the leaf spring, L, mm | 1376 |
| L1, mm | 694 |
| L2, mm | 682 |
| Total thickness, H, mm | 24 |
| Free camber, Ho, mm | 76 |
| D1, mm | 58 |
| d1 bushing inner diameter, mm | 16 |
| D2, mm | 54 |
| d2 bushing inner diameter, mm | 14 |
